BenQ MX880UST - Controls and Functions

Introduction10
Controls and functions
Projector
9. AUTO
Automatically determines the best picture
timings for the displayed image.
10. Keystone/Arrow keys ( / Up, /
Down)
Manually corrects distorted images
resulting from an angled projection.
11. POWER
Toggles the projector between standby
mode and on.
12. Right/
Activates panel key lock.
When the On-Screen Display (OSD)
menu is activated, the #3, #10, and #12
keys are used as directional arrows to
select the desired menu items and to make
adjustments.
13. SOURCE
Displays the source selection bar.
1. POWER indicator light
Lights up or flashes when the projector is
under operation.
2. MENU/EXIT
Turns on the On-Screen Display (OSD)
menu. Goes back to previous OSD menu,
exits and saves menu settings.
3. Left/
Starts the FAQ function.
4. MODE/ENTER
Selects an available picture setup mode.
Activates the selected On-Screen Display
(OSD) menu item.
5. BLANK
Used to hide the screen picture.
6. Focus ring
Adjusts the focus of the projected image.
7. TEMPerature warning light
Lights up red if the projector's
temperature becomes too high.
8. LAMP indicator light
Indicates the status of the lamp. Lights up
or flashes when the lamp has developed a
problem.
3
9
11
13
4
8
7
1
2
5
10
6
10
12
