Parts of the display and their functions12
VIDEO IN (DVI-D) Receives DVI signals from an external device (such as a
computer).
VGA IN Receives analog RGB signals from an external device (such as a
computer).
VGA OUT Outputs analog RGB signals from the VGA IN input to another
display.
RS232C IN/OUT For external control and multi-display operation.
• RS232C IN: receives control signals from a computer or
another display.
• RS232C OUT: outputs control signals from the RS232C IN
input to another display.
VIDEO IN
(COMPONENT)
Receives component video (YPbPr) signals from an external
device (such as a DVD player, HDTV device or Laser disc player).
VIDEO IN (S-
VIDEO)
Receives S-Video signals from an external device (such as a VCR
or DVD player).
VIDEO IN Receives composite video signals from an external device (such as
a VCR or DVD player).
VIDEO OUT Outputs composite video signals from the VIDEO IN input to
another display.
AC SWITCH ON/
OFF
Turns on or off the main power.
AC IN Connects to a power outlet via the supplied power cord.
AC OUT Relays the AC power from the AC IN jack to another display.
