User Manual www.dancohr.com page 5
Figure 1.2 Adjustable foot
• To mount the chair, adjust the height to about the level shown in.
• Then carefully cut the plastic plugs of the bottom with a small knife (see figure 1.3)
Figure 1.3
• Now the cover can easily be removed.
• The possibly remaining pieces of the 4 plugs can easily be removed with a tool.
• Now mount the chair to the floor.
• When you have a wooden floor only use the two supplied screws.
• When the chair is to be mounted on a stone or concrete floor first introduce the two supplied
wall plugs before mounting the chair with the screws. For drilling into a stone or concrete floor
you need a Ø 12 mm stone drill.
After having mounted the chair to the floor, both covers can be refitted to the chair. For this job you
need the 4 plugs and the tool
• Stick the supplied tool into one of the plugs.
• With a light stroke of a hammer the plugs are struck into the holes. Repeat this for the other 3
plugs.
The arm supports of the Bentlon
®
Podo Platinum are assembled as follows:
•
•
•
•
•
•
•
•
Figure 1.4 Fitting the arm supports
Move the metal arm support all the way up to its furthest rear position. Place the upholstery on the
underside of the arm. Then press the plastic cover over the upholstery so that it remains entirely in
position. To finish, securely tighten the screws provided using a flat screwdriver.
