Bentone B 30 A2.2H - Burner Installation; Working Field; Basic Settings - Fuel Oil

7 Bentone
2.3 Working eld
2.4 Basic settings - Fuel oil
d
1
d
2
d
3
d1 d2 d3
ø 110 10 ø 160-200
!
Do not exceed working
eld.
2.2 Burner installation
2.2.1 Hole patten
Make sure the hole pattern on the boiler is designed for burner ange.
0
20
40
60
80
100
0
2
4
6
8
10
75 100 125 150 175 200
160303-219
kW
Air settings
Nozzle assembly
Scale
1
Burner output
Air
2
<˚
1
Scale nozzle assembly and air damper without damper motor.
2
Settings air damper with damper motor.
-0,5
0,5
1,5
2,5
3,5
4,5
5,5
50 70 90 110 130 150 170
mbar
kW
4.5-15.0 kg/h
55-175 kW
160302-623-2
