6.2 Example of Basic settings
Basic settings should only be seen as setting values to get burner to start
and establish ame. Once the burner has started and established ame, it is
necessary to adjust the settings so that they are adapted to the installation
and the fuel used.
B 40 A
Burner output: 265 kW
Estimated nozzle output: 265 / 11.86* = 22.3 kg/h
(* Calorc value Fuel oil = 11.86 kWh/kg)
This provides the following nozzle according to the nozzle table, (see Technical
data).
Nozzle: 6.00 Gph
Pump pressure: 10.0 bar
Setting values for 265 kW according to basic setting diagram, (see Technical
data).
Air setting: = 8.0
Insert setting: = 2.0
