5.2 Patient positioning
5.2.1 Patient weight and size
NOTICE
The OPERON® Surgical Mobile Operating Table can be used in
both normal and reverse orientation. Its orientation depends on
where the patient's head is positioned. The dimension sheet
shows normal orientation. Normal and reverse orientations differ
in the maximum load capacity and the module adjustment op‐
tions.
1. Maximum load capacity in normal orientation: 1000 lb.
(454 kg)
2. Maximum load capacity in reverse orientation: 500 lb.
(227 kg)
3. Reverse orientation with split leg sections (optional) is not
possible.
5.3 Motion range limits
NOTICE
The add-ons and accessories can further restrict the motion rang‐
es.
NOTICE
1. If the Trendelenburg or reverse Trendelenburg angle is
larger than 15°, the maximum load for longitudinal slide
is 280 kg (226 kg for reverse orientation).
