NOTICE
In the unlikely event that the hand pendant and the emergency
hand pendant are deactivated, there is an emergency switch that
will release the table and allow it to move. It is connected directly
to the batteries. The batteries must still have enough voltage to
open the magnetic valves. The emergency switch is located in the
base near where the foot pump pedal is stored.
1. Keeping it straight, pull out the foot pump pedal to the first end stop.
2. Turn pedal counterclockwise.
3. Pull out the foot pump pedal to the second end stop.
Fig. 4: Emergency release
4. Stick your finger into the opening where the pedal is stored and press
the emergency release button.
¡
The power supply on the magnetic valve is activated, which releases
the OR table and allows it to be moved as long as the button remains
pressed.
9.4 Using the Auxiliary hand pendant
Operator Manual Surgical Mobile Operating Table Models D860, D850, D 830, D820, D770, D760
Malfunctions
99
