Visor
Door with lens
Halogen bulb
12V / 10W / G4
Reflector
Socket G4
Signal head, 3 parts,
with halogen lens
red – yellow – green
12
similar illustration
Signal head
Replacing the halogen bulbs
The halogen bulbs can be replaced quickly without needing special tools: all you need
is a medium-sized flat screwdriver.
Open the corresponding signal head chamber by using the flat screwdriver to press in
the two snap clips on the right front side of the control door so as to hinge the door
open. You are now looking at the back of the reflector: you can see four red ring eyelets
holding the reflector around the outside. Now lift these holders off the reflector
(without using a tool) and simply bend up all the ring eyelets. The reflector is released
and you can now pull the bulb out to the front.
Replace the defect halogen bulb (12V / 10W / G4). Place the reflector in the signal
head door and press the ring eyelets flush against the reflector again. Now close the
signal head door until it engages in the two snap clips – that's all!
