7
B114 (Fig. 8)
- Clean the blade, freeing it of
greasy residue;
- check that the guard is cover-
ing the blade properly;
- loosen the meat table from
the blade;
- lift the sharpener and rotate
it 180°;
- lower the sharpener with
care. The blade will be auto-
matically centred between the
two grinding wheels;
- push the sharpening lever
(B) for approximately 10-15
seconds and simultaneously
rotate the ywheel;
- release the sharpening lever,
press the button (C) for 2-3
seconds and then release it;
- stop turning the ywheel;
- only when the blade is xed,
return the sharpener to its
original position and relock the
knob;
- close the cover, if present.
FOR MODEL
B116 (Fig. 9)
- Clean the blade, freeing it of
greasy residue;
- check that the guard is cover-
ing the blade properly;
- loosen the meat table from
the blade;
- lift the sharpener cover;
- lift the sharpener and rotate
it 180° in the direction of the
blade;
- lower the sharpener with
care. The blade will be auto-
matically centred between the
two grinding wheels;
- press the button (A) for ap-
proximately 10-15 seconds
and simultaneously rotate the
ywheel. Release the button
(A), pull the lever (B) for 2-3
seconds and then release it;
- stop turning the ywheel;
- only when the blade is xed,
return the sharpener to its
original position and relock the
knob;
- close the cover.
FOR MODEL
L16, (Fig. 10)
- Check that the blade protec-
tion duly covers the blade;
- loosen the sharpener-locking
knob;
- lift the sharpener and rotate
it 180°;
- lower the sharpener back
down with care; the blade will
automatically center between
the two grinding wheels;
- re-lock the knob;
- pull the lever anticlockwise
for approximately 10-15 sec-
onds and simultaneously ro-
tate the ywheel;
- turn the lever clockwise for
approximately 2-3 seconds
and simultaneously rotate the
ywheel;
- stop turning the ywheel;
- only when the blade is xed,
return the sharpener to its
original position.
WARNING: risk of dam-
ages! Do not excessively
force (more than 2-3 seconds)
the deburring operation to
prevent damaging of the blade.
Lubrication (Fig. 11)
- Put some drops of oil over the
bar (1) and in the junction of
the slice thickness-regulating
knob (2);
- put some drops of oil in the
holes (3 and 4);
- put some drops of oil on the
ywheel in its junction to the
tree (5);
- briey activate the ywheel.
For lubrication only use acid
free oil (we recommend Vase-
line oil). Do not use vegetable
oil.
SERVICE
No user-serviceable parts are
inside. Refer servicing to qual-
ied personnel. All the repair
and replacement operations
(like blade replacement, repair
of structural parts, repair and/
or re-placement of sub-base-
plate components, or similar)
shall be executed exclusively
by personnel authorized by the
manufacturer.
In the event service is need-
ed, you may return your food
slicer to the manufacturer or
to one of the Authorized Ser-
vice Centers. For information
about service, centers please
contact us at:
service@berkelinternational.com.
WARNING: risk of in-
jury from sharp blade!
The blade replacement is
mandatory if distance be-
tween the edge of the blade
and the internal edge of the
guard exceeds 6 mm.
WARRANTY AND
RESPONSIBILITY
The manufacturer supplies The
manufacturer supplies ma-
chines with a limited war-ranty
of 24 months from the pur-
chasing date. The warran-ty is
extended only to defects that
arise under intended use condi-
tions and proper use. The war-
ranty does not cover defects
resulting from faults caused by
transport, purchas-er’s incom-
petence or negligence, improp-
er installation, unauthorised
interventions, natural wear
and tear greater than 10% of
the nominal value. More-over,
the warranty does not cover
components intrinsically sub-
ject to wear, such as blades and
!
!
