Master Valve Settings
The master valve is the valve which controls water flow to all other valves.
Perform the following steps to navigate to the master valve's settings:
1.
From the controller settings,
select the valve designated as
the master valve
2.
The master valve's settings
are displayed
The master valve's settings include:
Valve name – enables naming of the master valve
Output number – the physical output controller to which the master
valve is connected
Status – enables activating and deactivating the master valve
Valve description – enables adding text describing the master valve
Opening order – defines when the master valve opens in relation to
the regular valves
Closing order – defines when the master valve closes in relation to
the regular valves
Opening delay between master & valve – defines the delay time
between opening of the master valve and regular valve. This delay
is relevant when either the "master valve before valve" or "valve
before master valve" opening order was selected
Closing delay – defines the delay time between closing of the master
valve and regular valve. This delay is relevant when either the
"master valve before valve" or "valve before master valve" closing
order was selected
NOTE: The master valve is
selected in General Settings
