Berner 185139 - Resistance measurement; Ω

32
Capacitance measurement / F
Use the selector switch to set the appropriate range. Insert the
black test lead into the ‘COM’ socket and the red test lead into
the V/Ω/TEMP/CAP socket. Using the test probes, touch the
test points of the test object. Read measurement value on the
display.
Measurement
range
Resolution
Accuracy
2 nF
1 pF
± 4 % + 3 digits
20 nF
10 pF
200 nF
0.1 nF
2 µF
1 nF
20 nF
10 nF
Discharge the capacitors before every measure-
ment.
Resistance measurement / Ω
Use the selector switch to set the appropriate range. Insert the
black test lead into the ‘COM’ socket and the red test lead into
the V/Ω/TEMP/CAP socket. Using the test probes, touch the
test points of the test object. Read measurement value on the
display.
