Berner 185139 - Temperature; Frequency

34
Measurement
range
Function
◦))
The integrated buzzer signals up to a re-
sistance of 70 Ω
- Measuring voltage: approx. 2.8 V.
Temperature
Set the selector switch to "TEMP / °C". Place the supplied
temperature probe into the sockets "COM" and V/Ω/TEMP/CAP.
Touch the object to be measured with the measuring tip. Read
measurement value on the display.
Measurement
range
Resolution
Accuracy
-20 to 0 °C
1 °C
± 5 % + 5 digits
0 to 400 °C
± 2 % + 3 digits
400 to 1000 °C
± 1 % + 3 digits
Frequency
Set the selector switch to "Hz". Insert the black test lead into
the ‘COM’ socket and the red test lead into the V/Ω/TEMP/CAP
socket. Using the test probes, touch the test points of the test
circuit. Read measurement value on the display.
Measurement
range
Resolution
Accuracy
20 kHz
10 Hz
± 1.5 % + 10 digits
- Sensitivity: 200 mV
- Max. input voltage 10 Vrms
