Installation
Electrical data of the devices
Devices by power (3.5 kW- BIPMS3.5)
Induction cooktop 1-phase (voltage 230Volt +5% / -10%)
Connection
Color
Frequency
Backup
Phase
Brown, Black or 1
50 Hz / 60 Hz
1 x 20A F (fast)
N
Blau or 2
Working
frequency
22-35 kHz
Tax security
-
Pe
Yellow/Green
Devices by power (5 kW- BIPMS5)
Induction cooktop 2-phase (voltage 400Volt +5% / -10%)
Connection
Color
Frequency
Backup
Phase
Brown, Black or 1.2
50 Hz / 60 Hz
1 x 16A F (fast)
N
Blau or 4
Working
frequency 22-35
kHz
Tax security
-
Pe
Yellow/Green
Devices by power (5 kW, 7kW, 8kW, 9kW- BIPS)
Induction cooktop 3-phase (voltage 400Volt +5% / -10%)
Connection
Color
Frequency
Backup
Phase
Brown, Black, Grey or 1,
2, 3
50 Hz / 60 Hz
3 x 16A F (fast)
N
Blau or 4
Working
frequency 22-35
kHz
Tax security
-
Pe
Yellow/Green
Devices by power (10 kW double generator BIPDS)
Induction cooktop 3-phase (voltage 400Volt +5% / -10%)
Connection
Color
Frequency
Backup
Phase
Brown, Black, Grey or 1,
2, 3
50 Hz / 60 Hz
3 x 16A F (fast)
N
Blau or 4
Working
frequency 22-35
kHz
Tax security
-
Pe
Yellow/Green
Devices by power (3.5 kW- double generator BIPDMS3.5)
Induction cooktop 1-phase (voltage 230Volt +5% / -10%)
Connection
Color
Frequency
Backup
Phase
Brown, Black or 1
50 Hz / 60 Hz
1 x 20A F (fast)
N
Blau or 2
Working
frequency 22-35
kHz
Tax security
-
Pe
Yellow/Green
Functional conditions
o max. tolerance of mains voltage nominal voltage+5%/-10%
o Frequency50 / 60 Hz
o Protection class in delivery stateIP 11
o min. pan diameter12 cm
