Berner System 60/20 - Hot Holder with Spin Control; Powerstar Function Double Generator ( Devices with 400 V Double Generator BIPDS )

Page 20 Of 44 17.07.2014
Ver. 3.6 © Bernese cooking systems 2018
The Power Star QUnktIon Wird WIe Qolgt AktIvieRt:
Vordere KocHstelle Belegt, hintHee AusgeschaAccordingen=
3.5/5.0/7.0 kW
HintHee KocHstelle Belegt VordHee AusgeschaAccordingen=
Hot holder with Spin Control
The set temperature is set on the knob. The direction of rotation has no influence
function, as only the temperature control is supported with the hot holder.
Elements
Description
Function
Rotary switch
0 position
From
Rotary switch
Range α40°-320°
Temperature
The set temperature is displayed on the 3-digit display.
The LED ring is also connected to the set temperature range with abrightly
Displayed.
The actual temperature is shown as a weak luminous tail above or below the set temperature LED.
When the target temperature isreached, no tail is visible.
Elements
Description
Function
Arrow Right
indicates the function-dependent direction of
rotation
Arrow Left
indicates the function-dependent direction of
rotation
Temperature icon
illuminates with temperature control,
flashes in temperature mode when pot
detection
Powerstar function double generator ( devices with 400V double generator BIPDS )
There can be 2 cooking points with a maximum power of 1.8/3.5/5.0 kW each or only the front
cooker with 3.5/5.0/7.0 kW or the rear cooker with 3.0/5.0/7.0 kW.
Elements
Description
Function
On-Off button
Button for 1 sec to press
Switching on or off
On button
Setpoint setting
Quick press: increment in 2 steps
Long actuating: increment in 10 steps
From Taste
Setpoint setting
Quick press: decrement in 2 steps
Long actuating: decrement in 10 steps
