Power control with touch
Instead of the pot (Poti must NOT be connected) the touch display takes over
control.
The device is switched on by means of the on-off button.
Performance is set in whole increments from level 1 to 9.
(When the warming function is activated, the power control is done in half steps)
Power control with Spin Control
The set temperature is set on the knob. The direction of rotation has no influence
to the function, since in the induction cooktop without a warming function only the
performance control is supported.
Rotary switch
0 position
From
Rotary switch
Range α40°-320°
Power level 1-9
The power level is displayed on the 3-digit display in the middle.
For this purpose, the LED ring with a strongly luminous LED displays the power position parallel to
the rotary knob. When it is moved, a tail appears as an optical effect.
Arrow Right
indicates the function-dependent direction of
rotation
Arrow Left
indicates the function-dependent direction of
rotation
Performance icon
lights up with power control,
flashes in power mode when pot detection
Warming function (optional)
How do I use the warm-up function
When using this function by means of gags (W70-W110) or activating by the touch control
panel, the warming function is active. Attention must be made to ensure that the pot dishes
must always be placed in the middle of the cooking area (temperature sensor coil).
The warming function is released as an option for the induction cooktop individually per channel.
(see controls). Thus, the hob also has a temperature control in addition to the power control. The
use of the two functions is subject to the different operating concepts.
For grill and hot holder applications, the warming function has no meaning.
On-Off button
Button for 1 sec to press
Switching on or off
On button increment in 1 steps
Ab button decrement in 1 steps
