Bernina 1090 - Print L-1230 Т

Print 1-1230
heat sink and securing screws without
foil or insulating washer, because a
ll occur. The heat sink with its
Galvanically insulating foil must sit fully on the securing angle,
seporated in order to achieve best results in transfering heat
low voltage from the heat sink to the sewing machine housing.
Not used
Sewing light
Pover supply for
print S and А-КАО
Control signals
to print S-KAO
Connector for
print R-4200
Equalization of speed
‘Main Motor
voltages. Observe the
notice on page 17.
м” 11
