11
Preparation - Sewing
The FHS raises and lowers the presser foot.
Attaching the lifter
█
insert into the opening; you should be able to operate the FHS with your
knee in your normal sitting position
Raising and lowering the presser foot
█
with your knee push lever to the right
█
the presser foot is raised; the feed dog is lowered simultaneously. The
thread tension is released
█
the feed dog is raised as soon as the first stitch is sewn
Presser Foot Lifter (FHS) */**
█
the vertical spool pin is on the side behind the handwheel
█
it is an essential aid for sewing with more than one thread, i.e. double need-
le work
█
raise the pin until it clicks into its vertical position
█
when using large reels, add the foam pad A for stability
Vertical Spool Pin
Your dealer can adjust the FHS if necessary.
A
