15
Preparation - Sewing
Threading the First Thread
█
place thread spool on horizontal spool pin and thread
█
guide the thread to the front in the slit and past the tension disc A on the
right side
█
thread sewing computer as usual and thread the right needle
Threading the Second Thread
█
place thread spool on the vertical spool pin and thread
█
guide the thread to the front in the slit and past the tension disc A on the
left side
█
thread the left needle
█
threads must not be twisted together
█
two thread spools and one full bobbin are needed
█
place one thread spool on horizontal spool pin
█
place second thread spool and the bobbin, separated by a spool disc, on
vertical spool pin (both spools have to turn in the same direction)
█
thread as usual by guiding two threads on the left side of the tension disc A
and one thread on the right side of the disc
A
Threading the Double Needle
Threading the Triple Needle
A
033301.71.04_2014-02_Manual_B330_B350_PE_B380_EN
