13
Preparation - Sewing
Bobbin Case
To remove the bobbin case
█
raise needle
█
power switch to «0» (off)
█
open the bobbin cover
█
grasp the latch of the bobbin case
█
remove bobbin case
Bobbin thread cutter
█
insert the bobbin case
█
take the thread over cutter A and cut it
█
close the bobbin cover
To insert the bobbin case
█
hold the bobbin case latch
█
the finger on the case should point upwards
█
insert the case so that it clicks into place
A
The bobbin thread does not have to be brought up as the loose end
is just the right length to start sewing.
033301.71.04_2014-02_Manual_B330_B350_PE_B380_EN
