Bernina 330 - Stitch Plate; Thread Tension

17
Preparation - Sewing
Changing the Presser-Foot Sole
█
raise the needle and the presser foot shaft
█
power switch to «0» (off)
█
press the button on the shaft to release the sole
Attaching the presser-foot sole
█
place the presser-foot sole under the shaft so that the peg sits under the
opening of the shaft
█
lower the presser-foot lifter and the foot sole will click into position
Changing the Presser Foot
Changing the Presser Foot
█
raise the needle and presser foot
█
power switch to «0» (off)
Raising the Lever
█
raise the clamping lever
█
remove the presser foot
Attaching the Presser Foot
█
guide the foot upwards over the cone
█
press the clamping lever down
3
033301.71.04_2014-02_Manual_B330_B350_PE_B380_EN
