1.3 Overview of the quilting frame
1
2
3
4
11
10
17
9
14
12
6
5
7
13
1518 16
8
1 Legs, left 10 Cross bar, rear
2 Tabletops 11 Rail support, right
3 Rail support, left 12 Top rail
4 Backing rail 13 Cross bar, bottom
5 Dead bar 14 Legs, right
6 Machine 15 Track, front
7 Take-up rail 16 Legs, center
8 Storage tray 17 Carriage
9 Track, rear 18 Cross bar, front
