1.4 Overview of delivery
The machines in the BERNINA Q Series for quilting frames are delivered in three packages. Any special
accessories ordered additionally will be supplied in separate packages. These accessories are not taken into
account in these assembly instructions.
Cardboard box Content Size in cm (in) Weight in kg (lb)
1 Q Series machine, including
standard accessories
Approx. 112 × 77 × 42
(44.1 × 30.3 × 16.5)
Approx. 40
(88.2)
2 Large parts, tools and
accessories
Approx. 120 × 80 × 70
(47.2 × 31.5 × 27.6)
Approx. 75
(165.4)
3 Long parts Approx. 350 × 30 × 24
(137.8 × 11.8 × 9.5)
Approx. 66
(145.5)
1.5 Overview of large parts
The delivery contains the following large parts:
Cardbo
ard box
Number Large parts
1 1 Machine
2 3 Tabletops
1 Carriage
3 Legs: Right, left, center
2 Rail supports: Right, left
3 1 Cross bar, bottom
2 Cross bars: Rear, front
2 Tracks: Rear, front
1 Top rail
1 Backing rail
1 Take-up rail
1 Dead bar
