GASCONNECTION
Allgasconnectionsmustcomplywithnational
andlocalcodes.Thegassupplyline(service)
mustbethesamesizeorgreaterthantheinlet
lineoftheappliance.Thisrangeusesa1/2"NPT
inlet(seedrawingbelowfordetailsofgas
connection).Onallpipejoints useappropriate
sealant
resistanttogas.
ThisrangecanbeusedwithNaturalor
LP/Propanegas.Therangeisshippedfromthe
factoryforusewithLP/Propanegas.
ForNaturalhouseholdinstallation,theappliance
mustbeconvertedbythedealer,byafactory‐
trainedprofessionalorbyaqualifiedlicensed
plumberor
gasservicecompany.
Gasconversionisimportantforsafeandeffective
useoftheappliance.Itistheresponsibilityofthe
dealerandtheowneroftherangetoperformthe
appropriategasconversionfollowingthe
directionsofthemanufacturer.
THEGASCONVERSIONPROCEDUREISDESCRIBED
INTHISMANUALANDIN
THEPACKAGE
CONTAININGTHECONVERSIONNOZZLES
SHIPPEDWITHEVERYRANGE.
Pleaseprovidetheservicepersonwiththis
manualbeforeworkisstartedontherange.

WARNING!
DONOTUSEANOPENFLAMEWHENCHECKING
FORLEAKS!
Leaktestingoftheapplianceshallbeconducted
accordingtothemanufacturer'sinstr uctions.
Before
placingtheovenintooperation,always
checkforleakswithsoapywatersolutionor
otheracceptablemethod.

MANUALSHUT‐OFFVALVE
THISVALVEISNOTSHIPPEDWITHTHEAPPLIANC
ANDMUSTBESUPPLIEDBYTHEINSTALLER.
Themanualshut‐offvalvemustbeinstalledin
thegasservicelinebetween
thegashook‐upon
thewallandtheapplianceinlet,inaposition
whereitcanbereachedquicklyintheeventofan
emergency.
InMassachusetts:A'T'handletypemanualgas
valvemustbeinstalledinthegassupplylineto
thisappliance.

FLEXIBLECONNECTIONS
In case
 of installation with flexible couplings
and/or quick‐disconnect fittings, the installer
must use a heavy‐duty,  AGA design‐certified
commercial flexible connector of at least 1/2"
(1.3 cm) ID NPT (with suitable strain reliefs) in
compliance with ANSI Z21.41 and Z21.69
standards.
In Massachusetts: The unit must be installed
with
a36"(3‐foot)longflexiblegasconnector.
InCanada:useCAN1‐6.10‐88metalconnectors
forgasappliancesandCAN1‐6.9M79quick
disconnectdeviceforusewithgasfuel.

PRESSURETEST‐POINTSTOPPERVALVE
To avoid gas leaks, the pressure test‐point
stoppervalveandgaske t
suppliedwiththerange
mustbeinstalledonthegasfittingatthebackof
therangeaccordingtothediagrambelow.



 

