Bertazzoni MAS486GGASXTLP - Gas Conversion - Steps 4 & 5; Broiler Burner Nozzle Replacement; Post-Conversion Visual Checks

18
STEP4:BROILERBURNER
Loosenthescrewandpullouttheburnerfromits
support.
ATTENTION:payextraattentiontoavoiddamage
totheigniterandthermocouple.


Using a 7 mm [name of the tool] unscrew the
nozzle. Replace the nozzle using the conversion
set supplied with the range or by a Bertazzoni
authorized parts warehouse. Each nozzle has a
number indicating its flow  diameter printed on
the body. Consult the table on page 20 for
matching
nozzlestoburners.


AdjustthegapXbysettingittofullyopen
position.
STEP5:VISUALCHECKS
Beforereinstallingthebottompanel,the
followingvisualcheckmustbeperformedto
ensurethattheconversionhasbeencarriedout
properlyandwithoutdamagetoother
componentsoftherange.

A) CONNECTIONOFTHERMOCOUPLESTO
THERMOSTAT
Thethermocouplesforbothbroiler andmain
ovenburner
areconnectedtothesamemagnet.
Tightgentlythetwoconnectionsalternating
actiononthetwonuts.Donotfullytightenone
thermocouplebeforehavingstartedtotighten
thesecondone.


B) OVENIGNITERANDTHERMOCOUPLE
POSITION
Theappropriategapbetweenthetip ofthespark
plugorthermocoupleandtheburnershallbe
approximately1/8’’.


Thetipofthesparkplugorthermocouplemust
fullyoverlapatleastthefirstgasemissionholeof
theburner.
