Bertazzoni MAS486GGASXTLP - Gas Conversion - Steps 2 & 3; Surface Burner Nozzle Replacement; Main Oven Burner Nozzle Replacement

16
STEP2:SURFACEBURNERS
Toreplacethenozzlesofthesurfaceburners,lift
up the burners and unscrew the nozzles shipped
withtherangeusinga7mm{sochetwrench).
Replacenozzlesusingtheconversionsetsupplied
with the range or by a Bertazzoni authorized
parts warehouse. Each nozzle has a
 number
indicating itsflow diameter printed on the body.
Consultthetableonpage20formatchingnozzles
toburners.








STEP3:MAINOVENBURNER
Toreplacethenozzlesofthemainovenburner,
startbyremovingthebottompaneloftheoven.


Loosenthescrewlocatedontherightsideofthe
burnerandpullouttheburnerfromitssupport.
ATTENTION:payextraattentiontoavoiddamage
totheigniterandthermocouple.
Leftoven

