8
Fig 24
3. Function Instruction
3.1 Power Up Action
Power Up Self Testing Pan, Tilt, Camera Self-test Completion
Pan action: Pan rotate in certain direction and stop in zero coordinate.
Tilt action: Tilt rotate in certain direction and stop in zero coordinate.
Lens action: Lens zooms out to the widest angle.
From running the above actions to completing, power up self-testing finishes.
3.2 Basic Function
Dome Running
Control joystick or up, down, left and right key in the keyboard.
Zoom
Press ZOOM- button to make the lens farther and minify the scene.
Press ZOOM+ button to make the lens closer and magnify the scene.
Focus
After FOCUS- button is pressed, the object in vicinity will become clearer while the object far
away will become ambiguous.
After FOCUS+ button is pressed, the object far away will become clearer while the object in
vicinity will be ambiguous.
Iris
Press IRIS- to gradually shrink the iris and decrease the image brightness.
Press IRIS+ to enlarge the iris and increase the image brightness.
Preset Point
Setting preset press button “preset”+”number”+”enter”.
Calling preset press button “call”+”number”+”enter”.
<SYSTEM>
MFG
PROTOCOL ATUO
DOME ID
COMM
VERSION
