Automatic Uniform Sidedrive Carton Sealer (AS)
15
Installation/Setup
COMPRESSION ROLLERS: Adjust the compression rollers against the top edge of the box and
tighten the knobs to secure them in the operating position. [Fig. 2-3]
FRAME ADJUSTMENT: Turn electrical switch to the “ON” position to start the drive belts. Move the
box forward under the top tape head frame until taken away by the drive belts. If the box is hard to
move or is crushed, raise the frame slightly. If the box movement is erratic or stops under the frame,
adjust width adjustment crank slightly to add more pressure between the box.
CAUTION: IF DRIVE BELTS ARE ALLOWED TO SLIP ON THE BOX, EXCESSIVE BELT WEAR WILL
OCCUR.
[Fig. 2-3]
