BestPack AS22-2 - Roller Bed Parts List; Roller Bed Component Details

Automatic Uniform Sidedrive Carton Sealer (AS)
25
Drawings and Parts Lists
ROLLER BED PARTS LIST
BMFAAS22D
KEY NO. PART NO. QTY DESCRIPTION
1 10C040A1 1 FRAME, ROLLER BED AS22
2 C4104000 4 LEG, 18” EXTENSION M65X455
3 12554 4 BRACKET, EXTENSION M85X68X6
4 20008 2 SHAFT, T/HEAD M12X155 (BOLTED)
5 12453-2 8 ROLLER, ALUM M48X305
6 12452-13 8 SHAFT, ROLLER M9.5X330 RND/SLT
7 12453-1 10 ROLLER, ALUM M48X250
8 12452-4 10 SHAFT, ROLLER M9.5X275 SLTD
9 12453-10 13 ROLLER, ALUM M48X675
10 12534 13 SHAFT, ROLLER M9.5X700 RND/SL
11 C4129020 62 BUSHING, ROLLER CAP M45X30
12 E3154006 1 PLATE, FRONT BOTTOM TAPE HEAD (2” CONFIG.)
13 K6146001 1 BRACKET, PHOTO EYE SENSOR
14 K6147000 1 PLATE, SENSOR MOUNT
15 2702009 2 SCREW, FLAT HD PHILIP M4X12
16 2700032 2 SCREW, HEX HD M5X12
17 2701023 8 SCREW, SOCKET HD M8X20
18 2703206 2 SCREW, OVAL HD PHILIP M4X12
19 2700002 4 SCREW, HEX HD M6X12
20 P0006161 2 SCREW, KNOB M6X20
21 2850013 1 SENSOR, PHOTO E3JK-5M2
22 2705202 8 WASHER, SPLIT LOCK M6
23 2705203 8 WASHER, SPLIT LOCK M8
24 2705201 4 WASHER, SPLIT LOCK M5
25 2705102 8 WASHER, FLAT M6
26 2705101 8 WASHER, FLAT M8
27 2705103 4 WASHER, FLAT M5
*28 N/A -
29 2850014 2 REFLECTOR, PHOTO EYE E39-R1
30 K6148000 1 BRACKET, SENSOR MOUNT M522X236
31 K6149000 1 PLATE, MOUNT REFLECTOR M65X77
32 2702021 2 SCREW, FLAT PHILIP M5 x 16
* Item Removed
2
- Used on X” Cong. Only
X
2
