Automatic Uniform Sidedrive Carton Sealer (AS)
30
Drawings and Parts Lists
WIDTH DRIVE PARTS LIST
BMWAAS22D.1
KEY NO. PART NO. QTY DESCRIPTION
1
28110M17L 1 MOTOR, TH 110V 17:1 1/5HP LT
(28110M10L) 1 MOTOR, TH 110V 10:1 1/5HP LT (HIGH SPEED CONFIG.)
2
28110M17R 1 MOTOR, TH 110V 17:1 1/5HP RT
(28110M10R) 1 MOTOR, TH 110V 10:1 1/5HP RT (HIGH SPEED CONFIG.)
3 C4119000 1 PLATE, SBLT REAR MOUNT LH
4 C4120000 1 PLATE, SBLT REAR MOUNT RH
5 C8447000 4 PLATE, BRACKET MOUNT 112X16X6
6 C4111000 2 BLOCK, SLIDING TW1-6ACME (LH)
7 18006 2 BLOCK, SLIDING TW1-6ACME (RH)
8 A1109000 1 SHAFT, ADJ SCREW M25.2X772
9 A1110000 1 SHAFT, ADJ SCREW M25.2X804
10 A1118000 2 BLOCK, FRONT MOUNT M20 (L)
11 A1115000 1 HANDLE, STEEL ARM ASSEMBLY
12 C4133000 1 CAP, SCREW SHAFT
13 A1122000 2 COUPLER, DRIVE SBLT M35X39
14 K2106001 1 CHAIN, #35X258 W/ LINK
15 C4113000 2 SPROCKET, RS32X15TB
16 2701020 1 SCREW, SOCKET HD M6X16
17 2701021 16 SCREW, SOCKET HD M6X20
18 2701028 8 SCREW, SOCKET HD M6X80
19 2704002 4 SCREW, SOCKET SET M6X10
20 2704001 4 SCREW, SOCKET SET M6X6
21 2705102 10 WASHER, FLAT M6
22 2705202 25 WASHER, SPLIT LOCK M6
23 2706005 2 RING, RETAINING M16
24 2709008 2 KEY, M5X5X20
25 2709001 2 KEY, M5X5X25
26 12079 1 BRACKET, AIR REGULATOR MOUNT
27 K2147000 1 PLATE, ADJ WHEEL MOUNT
28 53337 1 ROLLER, CHAIN ADJUSTER M26X10
29 18029 1 SPACER, STANDOFF HEX H14X29.5
30 2700002 1 SCREW, HEX HD M6X12
Italic - Motor High Speed Conguration
