BestPack AS22-2 - Top Frame Parts List; Top Frame Component Details

Automatic Uniform Sidedrive Carton Sealer (AS)
33
Drawings and Parts Lists
TOP FRAME PARTS LIST
KEY NO. PART NO. QTY DESCRIPTION
1 K2401002 1 FRAME, TOP TAPEHEAD AS22
2 20058 2 PLATE, ANGLE MOUNT M102X100
3 18267 2 PLATE, MOUNT M25X50X6
4 20035 1 SHAFT, T/HEAD M12X163 (SPRING)
5 10115 2 SPRING, CUTTER BLADE ARM
6 20008 1 SHAFT, T/HEAD M12X155 (BOLTED)
7 L2417000 1 SHAFT, SQUARE COMP ROLLER 670L
8 20437 4 SHAFT, COMPRN ROLLER M15X38
9 20024-1 4 WHEEL, TOP COMPR’N GRAY
10 2700020 2 SCREW, HEX HD M6X16
11 2701021 8 SCREW, SOCKET HD M6X20
12 2701057 4 SCREW, SOCKET HD M8X40
13 2703202 2 SCREW, PAN HD PHILIP M5X15
14 2700002 2 SCREW, HEX HD M6X12
15 2702101 2 KNOB, LOCKING 3/8-13UNC
16 2705202 10 WASHER, SPLIT LOCK M6
17 2705203 4 WASHER, SPLIT LOCK M8
18 2705103 4 WASHER, FLAT M5
19 2705102 2 WASHER, FLAT M6
20 2705101 4 WASHER, FLAT M8
21 2707023 2 NUT, HEX M5
22 2707101 2 NUT, HEX JAM NYLOCK M5
23 2706004 4 RING, RETAINING M15
24 2700028 4 SCREW, HEX HD M8X16
25 L2409000 1 MOUNT, COMPRESSION LT
26 L2410000 1 MOUNT, COMPRESSION RT
27 K2402000S 1 PLATE, SKID TOP M456X181X1.6 2” (2” CONFIG.)
28 2701357 2 SCREW, OVAL HD M5X8 (2” CONFIG.)
BMDTAS22D.1
- Used on X” Cong. Only
X
2
2
