Automatic Uniform Sidedrive Carton Sealer (AS)
41
Drawings and Parts Lists
SAFETY GATES PARTS LIST
KEY NO. PART NO. QTY DESCRIPTION
1 104019C1 1 GATEPOST, ASSY LEFT FRONT L829
2 106034CA 1 SAFETY DOOR SET LEFT FRONT 495 x 639 x t25
3 104019C2 1 GATEPOST, ASSY RIGHT FRONT L829
4 106034CB 1 SAFETY DOOR SET RIGHT FRONT 495 x 639 x t25
5 084023D3 2 GATEPOST, ASSY 30 x 90 x 849
6 106034CC 1 SAFETY DOOR SET 525 x 639 x t25
7 2707003 8 NUT, M5
8 106034CD 1 SAFETY DOOR SET 525x639xt25
9 05500910 6 PLATE, JOINT - BEAM L 100 x 77 x t3
10 10402408 2 PLATE, MOUNTING - LATCH 198 x 134 x t3
11 05500909 6 SAFETY DOOR SET PLATE, MOUNTING 60 x 54 x t3
12 08402326 1 TUBE, FLAT - L 60 x 30 x t3 x 497L
13 08402327 1 TUBE, FLAT - R 60 x 30 x t3 x 497L
14 10603401 1 TUBE, FLAT - L 30 x 60 x 591 x t2.3
15 10603402 1 TUBE, FLAT - R 30 x 60 x 591 x t2.3
16 08402336 2 PLATE, 60 x 30 x t3
17 05500915 4 BLOCK, MAST MOUNTING 90 x 20 x t5
18 27402042 4 CAP, COMPRESSION GUIDE COVER 30 x 30
19
27402041 4 CAP, COMPRESSION GUIDE COVER 30 x 60
20
2740201 2 HANDLE A-42-G 131 x 114
21 D2330000 4 PLATE, MAGNETIC MOUNTING 60 x 44 x t3
22 D2321000 4 MAGNETIC ASSY.
23 2707007 4 NUT, HEX M4
24 2705103 20 WASHER, FLAT M5
25 2705102 34 WASHER, FLAT M6
26 D2320000 6 REAR LATCH SET
27 28530061 2 SWITCH, LIMIT OMRON Z-15GQ22-B
28 18348 2 SAFETY SWITCH MOUNT 60 x 50 x t3
29 2703214 1 SCREW, ROUND HD M4 x 25
30 2701032 28 SCREW, SOCKET HD M5 x 10
840232E2_1018
To Next Page
