Automatic Uniform Sidedrive Carton Sealer (AS)
45
CONTROL PANEL PARTS LIST
Drawings and Parts Lists
BMCPAS22D.1
KEY NO. PART NO. QTY DESCRIPTION
1 K6802001 1 BOX, ELECTRICAL M302X200
2 K6801010 1 PLATE, ELECTRICAL DRAWER
3 2811190 1 RELAY, THERMAL 4.0-6.0AMPS
4 2810117 1 RELAY, MAGNETIC SC-03-4A 110V
5 2896307-2 2 CAPACITOR, 16uf 250VAC
6 2861020 6 CONNECTOR, STRAIGHT MG-16A-10B
7 28701851 1 SWITCH, POWER M22-SFNC W/CONTACT
8 2843201 15 TERMINAL, BLOCK ELECT
9 2890023 1 HOLDER, FUSE SF-111A
10 2882401 1 CORD, ELECTL W/ PLUG 1.25 3M
11 2890043 1 FUSE, GLASS 10AMP 30mm
12 2801820 1 CIRCUIT BREAKER, KM FAZ-2-B20
13 2830108 3 RELAY, OMRON LY2NJ 110V W/ NEO
14 2831204 3 SOCKET, RELAY LY2NJ- PTF-08AM
15 2830005 1 RELAY, OMRON MY4N 14 PIN
16 2831205 1 SOCKET, RELAY 14 PIN MY4N
17 2843207 1 BRACKET, TERMINAL BLOCK SBN-20
18 2843202 1 TERMINAL, CONNECTOR END PLATE
19 2705006 2 WASHER, FLAT M4
20 2705103 2 WASHER, FLAT M5
21 2705102 3 WASHER, FLAT M6
22 2701501 2 SCREW, OVAL HD M6X12
23 2703203 1 SCREW, OVAL HD PHILIP M4X8
24 2703225 1 SCREW, OVAL HD PHILIP M4X10
25 2703206 2 SCREW, OVAL HD PHILIP M4X12
26 2703207 2 SCREW, OVAL HD PHILIP M5X6
27 2700026 1 SCREW, HEX HD M6X12
28 2707102 3 NUT, HEX JAM NYLOCK M6
29 2896327 2 BAND FOR CAPACITORS (6.8.16.18μF) 30Ø
