SPANNER TORQUE SETTINGS - GENERAL NUTS & BOLTS

ITEM SIZE X PITCH KGF M LBF FT (FT LBS) N M
M6 (7T) : 6MM (0.24IN) - 9.8~11.3 1.0~1.15 7.2~8.3
M8 (7T) : 8MM (0.31) - 23.5~27.5 2.4~2.8 17.4~20.3
M10 (7T) : 10MM (0.39IN) - 49.0~55.9 5.0~5.7 36.2~41.2
M12 (7T) : 12MM (0.47IN) - 77.5~90.5 7.9~9.2 57.1~66.5
SPANNER TORQUE SETTINGS - SPECIAL NUTS & BOLTS

ITEM SIZE X PITCH KGF M LBF FT (FT LBS) N M
HEAD BOLTS M12 X 1.25 98.1~107.9 10~11 72.3~79.6
BOLTS, CONNECTING BOLTS M10 X 1.25 78.5~83.4 8.0~8.5 57.8~61.5
BOLTS, FLYWHEEL M12 X 1.25 98.1~107.9 10~11 72.3~79.6
BOLTS, BEARING CASE M14 X 1.5 137.7~147.2 14~15 101.2~108.5
BOLTS, CRANKSHAFT M16 X 1.5 343.4~372.8 35~38 253.1~274.7
BOLTS, ROCKER ARM M10 X 1.25 49.0~61.8 5.0~5.7 36.2~41.2
GLOW PLUGS (BETA 75) M10 X 1.25 19.6~24.5 2.0~2.5 14.5~18.1
OIL SWITCH R 1/8 14.7~19.6 1.5~2.0 10.8~14.5
NOZZLE, HOLDER ASSEMBLY M20 X 1.5 49.0~68.6 5.0~7.0 36.2~50.6
NUTS, OVERFLOW PIPE M12 X 1.5 19.6~24.5 2.0~2.5 14.5~18.1
NUTS, INJECTION PIPE M12 X 1.5 22.6~36.3 2.3~3.7 16.6~26.8
NUT, INJECTION PUMP M14 X 1.5 73.5~83.4 7.5~8.5 54.2~61.5
