• Select each day individually, as days 1 through 7.
• Select all the days of the week, 1 through 7 appear
together.
• Select week day only, 1 through 5 appear together
• Select weekend days only, 6 and 7 appear together
Example:
1:45
1
P
DR2000MS03
The screen above indicates that the event will occur at 1:45 PM
every Monday (only Mondays).
Example:
8:30
1 2 3 4 5 6 7
DR2000MS07
The screen above indicates that the event will occur all days at
8:30 AM (everyday).
PROGRAMMING HOW LONG AN
EVENT WILL BE
Once you have programmed when the event will occur, press the
Event button again. The screen will display the day of the event
and the duration of the event in Minutes and Seconds. Min:Sec
will appear in the bottom of the screen. The maximum run time
is 19 minutes and 59 seconds. Set the duration of the event using
the Minutes button and the Seconds button. We recommend you
allow an interval of 20 minutes between events.
Example:
2:15
MIN:SEC
DR2000MS05
The above screen indicates that the event will have a duration of
2 minutes and 15 seconds.
Once you have finished programming the first event, press the
Event button again to move to next event. You can program up
to 24 events this way.
In situations where two events have been
programmed for the same time and day, the
highest numbered event will be the one the
DR-2000 accepts. For example, if event #1
is set for 30 seconds at 2:00 on day 1 and
event #4 is set for 10 seconds at 2:00 on
day 1, event #4 will take precedence and the
pump will activate for 10 seconds at 2:00 on
day 1.
CLEARING UNWANTED EVENTS
As a rule, it is a good idea to clear events that you do not plan to
use. This eliminates the occurrence of any unwanted events. To
clear unwanted events:
1. Go to the event screen of the first event you want to clear.
2. Press and hold the Hours and Minutes buttons.
3. While still pressing the Hours and Minutes buttons, press
and hold the Event button. The unit will scroll through all
higher-numbered events and clear them (by setting the
duration to “000”).
The unit will stop clearing after event 24.
Example of Clearing Unwanted Events
Let’s say you’ve programmed events 1 through 5 and are not
planning to use events 6 through 24. It is advisable to be sure
that there are no events programmed for 6 through 24. To do
this:
1. Go to the event 6 screen.
2. Press the Hours, Minutes and then Event buttons and hold
them down. The unit will scroll from event 6 through 24,
setting all values to “000”. This process will stop when it
returns to event 1. You now have events 1 through 5 as you
programmed them and events 6 through 24 cleared.
RETURNING TO RUN MODE
When you have finished programming, you can return to Run
Mode by pressing the Program button once. The colon will
again flash normally (once per second). If you leave the DR-
2000 in Program Mode and unattended for 2 1/2 minutes, it will
switch back into Run Mode automatically.
You can be sure you are in Run Mode by pressing the Prime
button and priming the pump. The Prime button will not prime
the pump if you are not in Run Mode.
PRIMING
1. Ensure that you are in Run Mode.
2. Press the Prime button to operate the pump.
ORDERING INFORMATION
SPARE PARTS
Main PCB 1202397
Power PCB 115 VAC 1202396
Power PCB 230 VAC 1202678
D-cell Battery Holder 1202596
Pump Motor Gearbox 6 VDC 057755
SnapHead Pump Cartridge 1/4 inch 058210
w/Silicone Tube
SnapHead Pump Cartridge 1/4 inch 1203790
w/Viton Tube
SnapHead Pump Cartridge 6 mm 1202707
w/Silicone Tube
DR-2000 (R14735-00, Rev C) February 2010 1210730 5
