Beta 1760/A - CAPACITANCE MEASUREMENT; DIODE TEST FUNCTION

EN
14
3.2.6 Capacitance
3.2.7 Diode
> Overload Protection: 250V DC or rms AC
> Forward DC Current: approximate 1mA
> Reversed DC Voltage: approximate 2.8V
Range Resolution Accuracy
2nF 1pF ±(4.0% of rdg +3digits)
20nF 10pF ±(4.0% of rdg +3digits)
200nF 0.1nF ±(4.0% of rdg +3digits)
2µF 1nF ±(4.0% of rdg +3digits)
20µF 10nF ±(4.0% of rdg +3digits)
Range Resolution Function
1mV Display: read approximate forward voltage of diode
