3.2.5 Resistance
> Open Circuit Voltage: 200MΩ range: 3V
Other ranges: less than 700mV
> Overload Protection: 250V DC or rms AC
NOTE: On 200MΩ range, if short input, display will read 1MΩ.
This 1MΩ should be subtracted from measurement results.
Range Resolution Accuracy
200Ω 0.1Ω ±(1.0% of rdg +10 digits)
2KΩ 1Ω ±(1.0% of rdg +1 digit)
20KΩ 10Ω ±(1.0% of rdg +1 digit)
200KΩ 100Ω ±(1.0% of rdg +1 digit)
2MΩ 1KΩ ±(1.0% of rdg +1 digit)
20MΩ 10KΩ ±(1.0% of rdg +5 digits)
200MΩ 100KΩ ±(5.0% of (rdg - 10 digits) +20 digits)
