3.2.1 DC Voltage
> Input Impedance: 10MΩ
> Overload Protection: 200mV range: 250V DC or rms AC
2V-1000V ranges: 1000V DC or 700V rms AC
NOTE:
At the little voltage range, the meter will show un steady reading when
test leads haven't reach the circuit, it's normal because the meter is very sen-
sitivity.
When test leads touch the circuit, you can get the true reading.
Range Resolution Accuracy
200mV 0.1mV ±(0.5% of rdg +1 digit)
2V 1mV ±(0.5% of rdg +3 digits)
20V 10mV ±(0.5% of rdg +3 digits)
200V 100mV ±(0.5% of rdg +3 digits)
1000V 1V ±(0.5% of rdg +3 digits)
