3.2.2 AC Voltage
> Input Impedance: 10MΩ
> Overload Protection: 200mV range: 250V DC or rms AC
2V-1000V ranges: 1000V DC or 700V rms AC
> Frequency Range: 40 to 400Hz
> Test On 60Hz/50Hz
> Response: Average, calibrated in rms of sine wave
NOTE: At the little voltage range, the meter will show un steady reading when
test leads haven't reach the circuit, it's normal because the meter is very sen-
sitivity.
When test leads touch the circuit, you can get the true reading.
Range Resolution Accuracy
200mV 0.1mV ±(1.2% of rdg +5 digits)
2V 1mV ±(1.0% of rdg +5 digits)
20V 10mV ±(1.0% of rdg +5 digits)
200V 100mV ±(1.0% of rdg +5 digits)
700V 1V ±(1.2% of rdg +5 digits)
