Beta 1760/A - DC CURRENT MEASUREMENT

EN
11
3.2.3 DC Current
> Overload Protection: 2mA to 200mA Ranges: F1:F200mA/250V fuse
10A Range: F2:F10A/250V fuse
> Max. Input Current: mA Jack: 200mA
10A Jack: 10A
> Voltage Drop: 200mV
Range Resolution Accuracy
2mA 1µA ±(1.0% of rdg +3 digits)
20mA 10µA ±(1.0% of rdg +3 digits)
200mA 100µA ±(1.5% of rdg +5 digits)
10A 10mA ±(2.0% of rdg +10 digits)
