4
ADJUSTMENTS
62
GB
ADJUSTING THE HOME POSITION OF
THE FRONT BRAKE LEVER
The home position of brake lever 2 can be
adjusted by means of screw 1.
ADJUSTING THE HOME POSITION OF
THE BRAKE PEDAL
The home position of brake pedal 3 can
be altered by turning adjusting screw 5 af-
ter loosening the counternut located under
dust cap 4. Loosen the counternut and turn
the adjusting screw until the desired height
is obtained. Retighten the counternut after
completing the operation.
1
2
3
4
5
