5
REPLACEMENTS
73
GB
Unscrew the two E screws and the four F
screws. Take off the rear fender.
E
F
F
F
F
Disconnect he connector A and unthread
the cable.
To reassebly the optical batch, insert before
the connector in the hole B, and then put
the cable as it shown in the picture.
A
B
