Better BT-532C - Page 10

BT-532C User manual
10
Select default line spacing
Name
Select default line spacing
Format
ASCII ：ESC 2
Decimal ：27 50
Hexadecimal ：1B 32
Description
Selects 33 dots line spacing.
Parameter range
N/A
Default
N/A
Supporting
model
All
Notes
The line spacing can be set independently in standard mode.Reference ESC 3n.
Usage example
N/A
Set absolute print positions
Name
Set absolute print positions
Format
ASCII ：ESC $ nL nH
Decimal ：27 36 nL nH
Hexadecimal ：1B 24 nL nH
Description
Set the distance from the beginning of the line to the position at which
subsequent are to be printed.
The distance from the beginning of the line to the print position is[(nL+nH
×256)×0.125 mm]
Parameter range
0 ≤ nL ≤ 255，0 ≤ nH ≤ 255
Default
N/A
Supporting
model
All
Notes
Settings outside the specified printable area are ignored.
In standard mode, the horizontal motion unit (x) is used..
Usage example
1b 40 1b 24 08 00
30 31 32 0d 0a
30 31 32 0d 0a
