BT-532C User manual
28
65
66
67
**** *
126
127
128
**** *
yL+yH×256dots
**** *
K-2
K-1
K
↓
7
6
5
4
3
2
1
0
MSB LSB
Usage example
1B 40
1d 76 30 00 03 00 09 00
FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF
FF FF
Define downloaded bit image
Name
Define downloaded bit image
Format
ASCII ：GS * x y d1...d(x×y×8)
Decimal ：29 42 x y d1 ...d(x×y×8)
Hexadecimal ：1D 2A x y d1...d(x×y×8)
Description
Defines a downloaded bit image using the number of dots specified by x and y.
x specifies the number of dots in the horizontal direction.
y specifies the number of dots in the vertical direction.
Parameter range
1 ≤ x ≤ 255
1 ≤ y ≤ 48
x*y ≤ 1536
0 ≤ d ≤ 255
Default
N/A
Supporting
model
All
Notes

The number of dots in the horizontal direction is x×8; in the vertical
direction it is y×8.

If x×y is out of the specified range, this command is disabled.

The d indicates bit-image data. Data (d) specifies a bit printed as 1 and
not printed as 0.

The downloaded bit image definition is cleared when:
