Overview
EN
1 Overview
1.1 Overview of the betterLink
3
4
1
5
6
1
7
8
2
Fig. 1 Overview of the betterLink.
1
Upper part of the locking device to secure betterPacks
on the betterLink
5
Connection for data cable
2
Slot for securing the betterLink to surface via screws
6
Connection for power cable
3
Dust cap
7
Data cable
4
Connection for betterPacks
8
Power cable
1.2 Scope of delivery
• betterLink
• Dust caps for the connections of betterPacks
• Power cable
• Data cable
• This user manual
1.3 Product line
To use the betterLink, you need betterPacks and the betterUI
designed by betteries. To view the complete list of compati-
ble devices, go to https://betteries.com.
1.4 Spare parts
Only use original spare parts which can be purchased from
the manufacturer or distributor.
Article number Designation
P/N 06-00095 Dust caps
P/N 04-00092 Power cable
P/N 04-00091 Data cable
