Using
EN
Fig. 7 Turning the wing screw.
6. Then turn the wing screw 180° in a clockwise direction.
Fig. 8 Folding the wing screw back down.
7. Fold the wing screw back down.
Fig. 9 Locked betterPack.
8. If needed, secure the position of the locking device with
a padlock.
9. To stack and lock additional betterPacks in the same
way, start by stacking a betterPack type “multi” and then
follow the given instructions for stacking betterPacks.
Fig. 10 Stacking betterPacks on the betterLink.
10. Before using, always check that betterPacks are properly
locked.
11. To remove the betterPack, first unlock the betterPack
again. To do so, li the wing screw, turn the wing screw
180° in a counter-clockwise direction and fold it back
down.
12. Carefully li the betterPack vertically upwards with
another person.
13. Set aside the betterPack in a safe place.
14. To protect the connections, put the dust caps back on the
connections.
