Quick Start Guide Quinta – Microphone Units
24
3. Quinta MU 23/22/21/MU 23 V/MU 21 V and Quinta MU 33/31 Microphone Units
3.1 Controls and Indicators
Power on and operating control LED
DC socket for charging the rechargeable batteries of the microphone unit or for DC operation
Charging contacts for charging in the CD 2 charger (Quinta MU 23/22/21/MU 23 V/MU 21 V)
or CD 3 (Quinta MU 33/31)
Headphone connection
Volume control for headphone connection
Quinta MU 23/22/21/MU 23 V/MU 21 V – Rear View Quinta MU 33/31 – Rear View
Q
uinta MU 33/31 – Lateral View
Quinta MU 33 – Front View
Quinta MU 31 – Front View
