Quinta – Microphone Units
19
 Loudspeaker
! “Clear” button to clear all delegate microphone units
 Microphone button
 Programmable function button
" Reset button to restart the integrated microcontroller (refer
also the item “Microphone unit cannot be switched off” in
chapter 8. “Trouble Shooting”)
% LED strips
Quinta MU 33 Chairman Microphone Unit
Quinta MU 31 Delegate Microphone Unit
Bottom of Microphone Unit Quinta MU 33/31
!  

"

Lateral View
% %
