1Machine Start up Switch
2Filter Holder
3Steam Nozzle
4Steam Knob
5Supply Group
6 Coffee supply key
7Water knob
8 Hot Water Supply
9Water tank (S version)
10 Power supply cable
11 Yellow light
12 Green light
13 Drain pipe (R version)
14 Water inlet nipple (R version)
15 Coffee distribution keypad
3 MACHINE DESCRIPTION
3.1 Machine Operating Cycle
The water coming from the water tank (S version), or from the wather supply (R
version) means of a vibration pump, fill the boiler and the heat exchanger.
The boiler water heated by a resistance, heats the water in the heat exchanger, which,
by means of a suction lift, allows to keep a constant temperature.
From the heat exchanger, the water goes directly into the group which, by an electric
valve controlled electrically by a push-button panel or by a key, allows the water to get
in for the coffee infusion.
3.2 Controls Description
