MOD. BEZZERA-B2016-OTTO -Woody
CONNESSIONI ELETTRICHE
ELECTRIC CONNECTION
BRANCHEMENT ELECTRIQUE
STROMANSCHULUSS
CONEXIÓN ELÉCTRICA
电气连接电气连接
CONEXÕES ELÉTRICAS
󼕳󺮟󾖴󼍟󺨟

V380-415/3+N
THREE-PHASE
󻸫󻸰󾖴󻨳
CONNECTION WITH
NEUTRAL
󼚀󻺠󺩫󼓇󾖴󼍟󺨟
V220-240/3
THREE-PHASE
󻸫󻸰󾖴󻃧󼸯
CONNECTION
󼍟󺨟
V220-240/2
SINGLE-PHASE
󻁗󼓫󾖴󼑳󻸰
CONNECTION
󼍟󺨟
V220-240/2
SINGLE-PHASE
󻁗󼓫󾖴󼑳󻸰
CONNECTION
󼍟󺨟
(0) Blu (Neutral)
󻮃󻙗󼐟󼚀󼬘󽋋
(0) Blu (Neutral)
󻮃󻙗󼐟󼚀󼬘󽋋
(0) Blu (Neutral)
󻮃󻙗󼐟󼚀󼬘󽋋
(0) Blu (Neutral)
󻮃󻙗󼐟󼚀󼬘󽋋
(0) White (neutral
for USA)
(1) Brown
󺥷󻸸
(1) Brown +(3) Grey
󺥷󻸸󽏻󻸸
(1) Brown +(2) Black
+(3) Grey
󺥷󻸸󺧯󼒯
󽏻󻸸
(1) Brown
󺥷󻸸
(1) Black for USA
(2) Black, 󺧯󼒯 (2) Black, 󺧯󼒯
(3) Grey, 󽏻󻸸
(3P+N+T) (3P+T) (1P+N+T) (1P+N+T)
380-415 Vac; 50-60
Hz
220-240 Vac; 50-60 Hz 220-240 Vac; 50-60
Hz
220-240 Vac; 50-60
Hz
