Instruction Manual
BGS technic KG
Bandwirkerstr. 3
D-42929 Wermelskirchen
Tel.: 02196 720480
Fax.: 02196 7204820
mail@bgs-technic.de
www.bgstechnic.com
AIR SOURCE
Clean air at the correct pressure is essential to supply this tool. The working pressure for this tool is
specified in chapter "Technical data" and is recommended for most compressed air tools of this class.
An increase in pressure is required if the length of the air hose or other circumstances result in a
decrease in pressure. The air pressure has to be increased in order to guarantee the working
pressure at running tool. Water in the hose and compressor leads to a reduction in performance and
damage to compressed air devices.
RECOMMENDED COMPRESSED AIR SYSTEM
Oiler (for tools with motor)
CONNECTING
1. Make sure the compressed air supply to the blow gun is shut off by turning the compressed air
shut-off valve (A) to the closed position.
2. Connect the compressed air nipple (C) of the hose to the compressed air connection coupling (B)
(Fig.1).
3. Now connect the compressed air nipple (D) of the blow-out gun to the compressed air coupling
(E) at the other end of the hose (Fig. 2).
4. Only switch on the compressor after all compressed air couplings have been checked for
tightness.
5. Turn the air shut-off valve (A) to the open position.
6. After completing the work, turn the compressed air shut-off valve (A) to the closed position and
release any remaining pressure in the system by operating the blow-out gun.
7. The blow-out gun can now be separated from the compressed air system.
